HT-2001/2002
1200W/575W电脑扫描灯
Scan Light
技术参数
电压:220V/50Hz
灯泡: HMl 575W / 1200W
耗电量:680W
控制信号: DMX512　
控制通道:8CH
尺寸:105×44×32CM
净重:33kg      毛重:37kg

TECHNICAL PARAMETER
Voltage:220V/50Hz
Lamp: HMl 575W / 1200W
Power Consumption :680W
Control Signal: DMX512　
Control Channels:8CH
Size:105×44×32CM
N. W:33kg      G. W:37kg

性能特点
7种色彩彩虹效果，6个可更换旋转图案(5个旋转图案,1个玻璃图案)
频闪,调光,开合光闸一体化,三棱镜,五棱和叠镜效果
水平170度,垂直90度扫描范围
二只轴流风扇致冷,内部优化风格设计,散热充分良好
内置过热保护,触发高压保护
接受国际通用DMX 512　标准信号
符合各种安全标准,IP20保护等级,外型采用新型铝合金外型设计,美观大方
电源线符合CE20/22三级标准
适用于大中小型娱乐场所,多功能演艺厅及迪斯科等场合

PERFORMANCE TRAIT
Applying new type aluminum alloy and casting steel plate shell design
The electronic circuit applies U.S new space chips group,
stable and strong ability inanti-interference
7 kinds of colors and rainbow effect
6 changeable rotating patters,5 rotating patterns ,
1 glass pattern Strobe,light adjusting integration design
Three,five and fold prism effect
Horizontal 170° and vertical 90°scanning range
2 convection cooling-fan ,optimize internal air duct way,
heat elimination rapidly
Built-on over heat protection and high voltage protection.
Compatible with DMX512 international digital signal
PFC power factor compensation
According to various kinds of safety standards,IP20protectgrades,
The cable accords to the CE20/22 standard
Suitable for large middle and small performance occassios,
the multifunctional studio and Disco
