详细资讯
Detail Info
|
|
|
|
|
|
|
HT-2003/2004
滚筒扫描灯
Scan Light Series
技术参数
电压:AC110V-220V 50Hz/60Hz
灯泡: NSD 150W
功率:200W
控制信号: DMX512
控制通道:6CH
尺寸:660×360×275mm
净重:11kg 毛重:13kg
TECHNICAL PARAMETER
Voltage:AC110V-220V 50Hz/60Hz
Lamp: NSD 150W
Power Consumption :200W
Control Signal: DMX512
Control Channels:6CH
Size:660×360×275mm
N. W:11kg G. W:13kg
性能特点c
8种色彩可双向高速及慢速彩虹滚动效果，8种可更换图案（含一款玻璃
图案），可按要求定做标志、特殊图案。图案内传功能，快速、慢速、
正正转、反转自由调节。机械线条性调光及1-7次/秒频闪效果
水平153.4°，垂直51.5°扫描范围动作平滑、流畅、定位准确，水平垂
直运动位置可精确调整。DMX通道首地址、使用时间、通过数码管直观
显示。地址与功能码按键式设置、贮存。可选择内置音乐触发及自组联
机按内部程序工作，而不需要外部控制器。一只对流风扇致冷，内部优
化风格设计，散热充分良好。接收DMX512国际标准数码信号
古河各种安全标准，IP20保护等级电源线符合CE20/22
PERFORMANCE TRAITc
8 colors,achieving high speed double way rainbow and scrolling effect
8 Kinds of changeable patterns(inclding 1 glass glass pattern),customer
oriented signal and special pattern are available.Pattern internal rotting
function,freely adjusting fast,low speed,clockwise and anticlockwise
Mechanical linear DIMMER and 1.7times/s STROBE effect
Horizontal 153.4°and vertical 51.5°scanning range,smooth
scanning action and accurate orientation precise adjustment on
horizontal and vertical position.DMX channel digit displays address
and using time.Setting and storing and storing the adress and
function codes by pressing the buttons
Music startup and self group online runs according to the
building program,no need of external controller
1 convection cooling fan,optimize internal air duct way,heat elimination
rapidly.Compatible with DMX512 international digital signal
According to various kinds of safety standards,IP20 protect
grades,The cable accords to the CE20/22 standard
|
|
|
